12W MT7620A 3G 4G Wifi Router USB Port 300Mbps For Home

Product Categories
Shenzhen Zhibotong Electronics Co., Ltd.
Contact Now

12W MT7620A 3G 4G Wifi Router USB Port 300Mbps For Home

Brand Name : OEM/ODM

Model Number : WE826-T2

Certification : FCC/CE

Place of Origin : China

MOQ : 3pcs

Price : Negotiable

Payment Terms : T/T, Western Union

Supply Ability : 100000units per month

Delivery Time : 3-25days

Packaging Details : 20units/carton

Main : MT7620A

Ram : 128MB (MAX DDR2 256MB)

Max Power Consumption : <12W

Work Channel : 2.4GHz choose: 1-13

Work Frequency : 2.4GHz

Flash : 16MB (MAX 32MB)

Wireless Rate : 300Mbps

Antenna : 2* 5dBi antenna or 4*5dbi external antenna (With 3G/4G)

Contact Now

Home use wireless router 3G 4G wifi router with USB and sim card slot

Note

The default WE826-T2 do not include 4G module. if you need it, please can let us know inadvance when you place order.

Product Specification

Band & Frequency
FDD LTE B1/B2/B3/B4/B5/B6/B7/B8/B28
TDD LTE B40
WCDMA B1/B2/B5/B8
GSM B2/B3/B5/B8
Hardware
Main Chipset MT7620A
RAM DDR2 128MB (MAX DDR2 256MB)
SPI FLASH 16MB (MAX 32MB)
Protocol IEEE 802.11n, IEEE 802.11g, IEEE 802.11b,
IEEE 802.3, IEEE 802.3u
RT Power

802.11b 18dBm±2dBm;

802.11g 15dBm±2dBm;

802.11n 15dBm±2dBm;
Reception Sensitivity

802.11b: -83dBm@10% PER

802.11g: -74dBm@10% PER

802.11n: -68dBm@10% PER
Work Channel

2.4GHz choose :1-13

5GHz choose :149, 153, 157, 161, 165
Wireless Rate Max 300Mbps
Work Frequency 2.4GHz
Antenna 4*detachable antennas
Interface

1*PCI-E slot

1*SIM card slot

1*USB 2.0 port

1*Micro SD card slot

1*10/100/100M WAN port(Auto MDI/MDIX)
4*10/100/100M LAN port(Auto MDI/MDIX)
LED Power,PCIE mode ,2.4G,WAN,LAN1,LAN2,LAN3,LAN4
Button Reset/WPS
Max Power consumption < 12W
Dimension(L*W*H) 141*85*26MM
Software
WAN Type PPPoE,Dynamic IP, Static IP
Work Mode

AP;

Router;
DHCP Server, Client, DHCP Client List, Address Reservation
Port Forwareding Virtual Server, Port Triggering, UPnP, DMZ
Firewall Security

Dos, SPI Firewall

IP Address Filter/MAC Address Filter/ Domain Filter

IP and MAC Address Binding
DDNS Support
VPN Pass-Through PPTP, L2TP, IPSec (ESP Head)
Band Ctrl Support
Static Router Support
System Log Support
Other Function Mac clone
NTP Synchronize
Web firmware upgrade
Others
Work Environments

Operating Temperature:0℃ ~ 40℃；
Storage Temperature:-40℃~ 70℃；

Operating Humidity:10%~90% non-condensing
Storage Humidity:10%~90% non-condensing
Adapter 12V 1A
Authentication CE, FCC, RoHs
Other accessories

Power adapter

ZBT-WE826-T2-specification.pdf

Detailed Picture

12W MT7620A 3G 4G Wifi Router USB Port 300Mbps For Home

12W MT7620A 3G 4G Wifi Router USB Port 300Mbps For Home
